2018 PRIMA POWER Laser Genius LGf 2040 Laser cutting machine (Fiber)

Ref. 3614720312
Brands PRIMA POWER
Models Laser Genius LGf 2040
Types of machine Laser cutting machine (Fiber)
Category 2D Laser Cutting Machines
Year 2018
Availability Available
Request a quote

Technical Data

Beam ON Working hours3.800 h
Dimensions (long x wide x high)12.600 x 4.080 x 2.200 mm
Laser Output6 kW
Machine ON Working hours13.835 h
Maximum material thickness aluminium6 mm
Maximum material thickness cupper5 mm
Maximum material thickness mild steel20 mm
Maximum material thickness stainless steel12 mm
Positioning speed X/Y200 m/min
Simultaneous positioning speed240 X+Y m/min
Weight11.000 kg
Working area (X x Y x Z)4.000 x 2.000 x 150 mm
